26-2022LF Lead Free 1/4 Turn Dual Outlet Angle Supply Valve 1/2 in. Nom Comp Inlet x 3/8 in. O.D. Comp x 3/8 in. O.D. Comp
26-2022LF Lead Free 1/4 Turn Dual Outlet Angle Supply Valve 1/2 in. Nom Comp Inlet x 3/8 in. O.D. Comp x 3/8 in. O.D. Comp
• Chrome Plated Lead Free Brass
• cUPC, NSF/ANSI 61 Approved
• Certified to ASME A112.18.1 / CSA B125.1
• Dual Outlet Dual Shut-Off
• 125 PSI
• Angle
• Temp. Rating: 32°F - 160°F
• 1/2 in. Nom Comp Inlet x 3/8 in. O.D.
Comp x 3/8 in. O.D. Comp
Material Specifications
| No. | Part | Material | QTY | ||||||
|---|---|---|---|---|---|---|---|---|---|
| 1 | Body | Brass C46500 | 1 | ||||||
| 2 | Packing | PTFE | 4 | ||||||
| 3 | Ball | Brass C46500 | 2 | ||||||
| 4 | Packing Nut | Brass C38500 | 1 | ||||||
| 5 | Outlet Nut | Brass C46500 | 2 | ||||||
| 6 | Stem | Brass HPB59-1 | 2 | ||||||
| 7 | O-Ring | NBR | 4 | ||||||
| 8 | Handle | ABS | 2 | ||||||
| 9 | Bolt | Stainless Steel | 2 | ||||||
| 10 | Sleeve | Brass H62 | 2 | ||||||
| 11 | Packing Nut | Brass C38500 | 2 | ||||||
| 12 | Sleeve | Brass H62 | 1 | ||||||
